Specification:

• Model : SF212-10, SF212-20, SF212-30, SF212-50
• Motor Power(w): 120
• Overall Dimension:

1. SF212-10: 500*500*2100
2. SF212-20: 500*500*2200
3. SF212-30: 540*540*2300
4. SF212-50: 540*540*2520

• Jacket Volume (L):

1. SF212-10: ≈3.8
2. SF212-20: ≈5
3. SF212-30: ≈8
4. SF212-50: ≈15

• Number OF Reactor Lid Opening: 6 Opening
• Temperature Measuring Hole: Φ35/Display Thermometer
• Dripping Hole: #40/1000ml Constant Pressure Funnel
• Reflux Port: Φ50 Ball Mouth/500ml Return Bend
• Feeding Port: Φ80
• Liquid Feeding Hole: #34 Glass Valve
• Stirring Hole: Φ60 Four-leaf
• Pressure Gauge: ±Integrated Pressure Gauge
• Outer Diameter Of Reactor Lid (mm): 265
• Outer Diameter Of Reactor Body (mm): >215
• Height Of Kettle Liner (mm):

1. SF212-10: <450
2. SF212-20: <550
3. SF212-30: <730
4. SF212-50: <850

• Inner Diameter Of Kettle liner (mm):

1. SF212-10: 290
2. SF212-20: 330
3. SF212-30: 365
4. SF212-50: 410

• Outer Diameter Of Discharge Port: Φ32
• Inner Diameter Of Discharge Port: DN25
